Microscopy > Microscopes > Inverted microscopes > Euromex > F-Serie > Euromex Microscope FE.2915, inverse
Product no.: 9337

Microscope FE.2915, inverse

$ 5,400.00 incl. VAT plus shipping costs
too expensive?
long-term
Product not available anymore + lead time

Product description

The Euromex microscopes of the F-series are routine and research microscopes, which are used in higher education, science and in biological, medical and industrial laboratories. The inverted microscopes in this range are suitable for studies of cell cultures and Hydrobiology. The microscopes give a crisp, flat image. The big eye lenses of the eyepieces suitable for eyeglass wearers and guarantee a relaxed observation.

The FE.2915

This model comes with a DIN eyepieces KHWF with 10 times magnification and 3 Infinity Semi-Plan objectives with a 4-fold, 10-fold and 20-fold magnification. Thus a maximum of a 200-fold magnification is possible.

The third vertical tube is suitable for connection of photo or video cameras. If the phototube is turned on, 80% of the light passing through the phototube. The remaining 20% to the eyepieces.

Specifications

Optics


Magnification
200 (40, 100, 200)
Eyepiece
10 (HWF eyepiece)
Condensor
einlinsiger Kondensor (N.A. 0.30, height adjustable)
Lighting
Incident light and transmitted light
Lamp type
Halogen (6V/30W, continuously adjustable, centerable, Köhler illumination)
Lens type
Infinity Type Semi-Plan Achromatic
Power supply
Power plug

Mechanics


Focusing
Coarse and fine movement (coaxial, with 0.0025 mm division)
Type of build
Trinocular
Specimen stage
Cross table (112 x 72 mm on specimen stage: 180 x 200 mm)
Viewing posture
30° angled eyepiece, rotatable head

Special features


Built-in digital camera
-
Centering stage
-
Rechargeable battery operation
-
Filter holder
yes
Luminous field diaphragm
yes
Dust cover bag
yes

General


Series
F-Serie
Colour
black-white
Weight (g)
11700
Suitable from
16

Suitable for


Beginners
-
Advanced
-
Pros
yes

Area of application


Interference contrast
-
Phase contrast
-
Polarization
-
Fluorescence
-
Metallurgy
-
Dark field
-

Product safety

Manufacturer: Euromex Microscopen bv, Papenkamp 20, 6836 BD Arnhem, NL, http://www.euromex.com (neu), http://www.euromex.nl/de
