Fiber Optical Light Guide
GLS -450-4.5
Since only high-quality glass fibres are used in the manufacture of the light conductor and the entire production process is subject to strict quality control, it transports light to where it is needed with virtually no loss. The light conductor is available in two different lengths for different applications. The light conductor (for optical sockets with a diameter of 15 mm) fits all StarLight cold light sources as well as corresponding instruments from other manufacturers. In other cases, adjustments and customised designs are possible at any time. The light conductor can be optimally positioned with accessories.
- For halogen and LED light sources
- Low heat generation on the object
- Versions with several freely movable arms
- Very good transmission
- High flexibility and light output
- Point-like lighting
- Adaptable to light sources from all manufacturers
- Customisable to customer requirements
Technical Data
- Number of arms 2
- Diameter active light guide 4,5 mm
- Length 1000 mm
- Light guide access Standard 15 mm
- Diameter light output 13 mm
- Diameter light input 15 mm
- Outer tube diameter 10 mm
- Illumination point-like
- Beam angle 70°
- Temperature input (light source) max. 240°C
- Ambient temperature max. 80°C
- Material tube Steel spiral, PVC
