Microscopy > Microscopy accessories > Miscellaneous > Miscellaneous > Dino-Lite > Connect Wireless > Dino-Lite WIFI Streamer WF-20 for AF-models
Product no.: 76937

WIFI Streamer WF-20 for AF-models

$ 379.00 incl. VAT plus shipping costs
too expensive?
short-term
ready for shipping in 3-7 days + lead time

Product description

Dino-Lite WF-20

Coupling with Dino-Lite AF series, the WF-20 is a Wi-Fi streamer adding further versatility, flexibility, and agility to Dino-Lite microscope. Thanks to stable image transmission and long battery life (more than 2.5 hours), the WF-20 is well suited but not limited to field applications. The WF-20 can also be configured as a wireless router for staying connected with the internet or a network during usage.

The WF-20 allows AF microscope models to be used wirelessly in connection with an iOS (iPhone/iPad) or Android app on any tablet, smartphone or even in the DinoCapture 2.0 software for Windows computers. The WiFi streamer is ideal for field work or presentations and can stream from one Dino-Lite to multiple devices. When using the iOS app or DinoCapture, users can perform measurements and take advantage of the automatic magnification reading (AMR) with compatible Dino-Lite AMR and measurement models. The WF-20 can be used anywhere to create a WiFi signal for streaming the Dino-Lite live images. The free DinoConnect App for WF-20 can be downloaded from the App Store or Google Play.

For (non "AF") USB microscope models, see the WF-10 for wireless options.

Specifications

Compatibility

  • Operating system: Windows 7, 8, 10 & 11, iOS 8.0 or later, Android 4.4 or later
  • Included software: DinoCapture 2.0 (Windows), DinoConnect App
  • Compatible with: AF4x15 series

Housing

  • Dimensions: 58 mm (L) x 36 mm (W) x 32 mm (H)
  • Weight: 57 g

Features

  • ESD safe: No
  • Frequency: 2.412 GHz~2.485 GHz

Information

  • Package contents: WF-20 WiFi streamer, user manual, mini USB charging cable, integrated Li-Ion battery
  • Accessory range: Wireless

Specifications

Capacity


Interface
WiFi

Special features


Rechargeable battery operation
yes

Camera


Software
DinoCapture 2.0 (Win); DinoConnect App
Supported operating systems
Windows 7, 8, 10 & 11, iOS 8.0 or later, Android 4.4 or later

General


Weight (g)
57
Length (mm)
58
Height (mm)
36
Width (mm)
32
Series
Connect Wireless

Field of application


Industry
yes
Education
yes
Hobby
-
Medicine
-

Area of application


Odontotechnics
-
Semiconductor technology
-
Metallurgy
yes
Veterinary medicine
-
University
-
Materials technology
yes
Naturopathy
yes

Miscellaneous


supplier product number
WF-20

Product safety

Manufacturer: Metav Werkzeuge GmbH, Parkring 45, 46446 Emmerich, DE, www.metav-shop.de
Dino-Lite WIFI Streamer WF-20 for AF-models
Dino-Lite WIFI Streamer WF-20 for AF-models
Dino-Lite WIFI Streamer WF-20 for AF-models
Dino-Lite WIFI Streamer WF-20 for AF-models
